Plastic Board Production Line
Details
：
Main Technical Parameter
The production line fits for making PVC plastic boards, corrugated plate and ladder boards with various specs. Main frame adopts SJZ taper dual screw extruder as one high-speed and high efficient plastic extruder with wide application, various plastic products, such as pipe, profiled materials, plastic-steel door and window profiled materials can be produced if relevant die head and assistant machines are equipped.
Main Technical Parameter
|
Model
|
SJZ-55
|
SJZ-65
|
SJZ-80
|
|
Screw Diameter mm
|
ф55/100×2
|
ф65/120×2 ф65/132×2
|
ф80/143×2
|
|
Screw Speed r/min
|
1-40
|
1-36.9
|
1-34.7
|
|
Main Motor KW
|
22
|
37
|
55
|
|
Barrel Heating Power KW
|
15
|
22
|
36
|
|
Productivity kg/h
|
150
|
250
|
360
|
|
Power of Drawing Machine KW
|
2.2
|
4
|
5.5
|
|
Speed of Drawing m/min
|
0.5-5
|
0.5-8
|
0.5-10
|
|
Power Vacuum KW
|
2.2
|
4
|
5.5
|
|
Machine Center Height mm
|
|
1000
|
1000
|
|
Total Weight kg
|
3800
|
4500
|
5600
|
|
Form Factor mm
|
20×1.5×2.4
|
22×1.8×2.5
|
26×2.2×2.6
|
|
Specification Board mm
|
Thick 1-3
Width 72-90
|
Thick 2-5
Width 72-90 |
Thick 3-10
Width 70-1200 |
